JingHong Device
1 / 5
| Processor | CPU Terrace | Intel 8 / 9 / 10 generations 45W CPU | Memory | Type | DDR4: 2133MHz/2400MHz/2666MHz/3200MHZ |
| Model | i7-10750H / i5-10850H / i9-9880H / i7-9750H / i7-8750H etc. | Slot | 2*DDR4 S0-DIMM up to 64GB | ||
| Video Card | Intel® UHD Graphics Support for GTX1650 4G / RTX2060 6G | ||||
| Front Panel | Power | 1*Power button | Expansion | WiFi Slot | 1*M.2 2230 slot (WIFI / BT support), WIFI 802.11 b/g/n/AC/AX |
| USB | 2*USB2.0 | SSD Slot | 1*M.2 2280 (SATA/NVME Gen3X4) + 1*M.2 2280 (SATA/NVME) | ||
| Back Panel | Power Port | 1*DC Jack 5.5*2.5mm (12-19V) | HDD | 1*SATA HDD 2.5inch (optional) | |
| Network | 1*RJ45 1000M | Size | 303 * 263 * 63mm (base 110mm) | ||
| Display | 1*HDMI 1.4 (4K 30HZ), 1*HDMI 2.0 (4K 60HZ), 1*Type-C (4K 60HZ) | Weight | About 1300g | ||
| USB | 4*USB3.2 Gen1 | Adapter | 19V 150W | ||
| Audio | 1*3.5mm earphone / 1*3.5mm MIC in | BIOS | AMI UEFI BIOS, Support for PXE, WOL | ||
| Working Env | Temperature: 0~50℃, Humidity: 5%~95% | Storage Env | Temperature: -20~70℃, Humidity: 5%~95% | ||
Mini PC realizes ray tracing for the first time. Equipped with NVIDIA RTX 2060 (6GB GDDR6) or GTX 1650 (4GB GDDR5), graphics performance is improved by 400% compared with previous generations, supporting DLSS 2.3 and ray tracing technology.
Dual-fan turbo cooling system ensures GPU continuous power consumption release reaches 80W. Graphics card is directly connected to CPU PCIe 3.0x8 channel, reducing latency to 1.2μs.
Perfect for real-time rendering (Enscape frame rate up to 58fps) and 4K film special effects (Blender Cycles rendering time shortened by 37%).
Dual M.2 2280 slots (NVMe Gen3x4 RAID 0 mode reads 6,200MB/s). Includes a 2.5-inch HDD anti-vibration bracket with 50G impact protection, supporting up to 18TB mechanical disks.
Ideal for security monitoring (32-channel 1080P stream 7×24h storage) and UAV mapping cold backup (-20℃ environment support).
HDMI 2.0 (4K@60Hz) + HDMI 1.4 (4K@30Hz) + Type-C DP Alt Mode (4K@60Hz). Supports 10-bit color depth and HDR400 certification (Delta E＜2).
Supports Esports live broadcast consoles (3 independent screens for gaming, chat, and monitoring) and medical imaging consultations (synchronous CT/MRI/PET display).
303×263×63mm all-steel body (1300g) with honeycomb air ducts (65% efficiency increase). Features removable IP5X dustproof nets and supports -20℃ cold starts.
150W smart power supply (92% efficiency) and optional dual Gigabit network aggregation for 2Gbps transmission.
RTX 2060 accelerates SolidWorks rendering by 43%. Digital signage supports 3-screen display and 100,000 hours of advertising materials on hot-swappable HDDs.
CUDA accelerates OpenCV algorithms for defect detection up to 1,200 pieces/minute. Wide temperature support for stable operation in industrial workshops.
